Sheet CCD counterpoint screen printing machine

  • Category:Screen Printing Machine
  • Number of views:0
  • Release time:2022-12-14 15:47:39
  • Product overview

  Product application scope:

  Sheet CCD matching screen printing machine is suitable for automatic printing of PET, PVC, PC, BOPP thin film label nameplate, film switch, fancy paper, IMD, IML, mobile phone composite materials and other sheet materials, the speed can reach 550-600pcs/hour.

  Product features:

  1.CCD image automatic alignment of high precision screen printing machine, manipulator loading and unloading, alignment accuracy +0.02mm, superior performance, greatly improved production yield. Machine structure, strong, light weight, imported servo and drive motor. Precision oriented positioning, stable operation, quiet and smooth fast.

  2. The printing table is made of aluminum, the flatness of the table is +0.07mm, and the thickness of the printing film is uniform.

  3. The design of synchronous locking device for casting column and precision linear guide rail of the printing stand ensures the thickness uniformity of the printing film.

  4. Servo motor lifting screen and traditional printing with high precision digital constant pressure printing head, so that the printing press can fully show the constant pressure effect.

  5. Specially designed for the automatic line printing of single sheet material automatic inlet and outlet section, directly improve the productivity and quality yield.

  6. Equipped with safety return, automatic error detection system, safety grating, emergency stop button, warning lamp post and other safety design.



  Technical parameters:

Technical parameter


 Workshop layout diagram:

Workshop layout diagram

Workshop layout diagram
